AC STAMFORD TYPE ALTERNATOR TR274

Product Item : TR274
Category： ALTERNATOR
Stamford Type Alternator
4 poles 1500RPM 1800RPM
SIngle Phase Three phase
Product description：DINGOL WERNA FARADAY FARRAND ALTERNATOR WR274C WR274D WR274E WR274F WR274J WR274K DG274C DG274D DG274E DG274F DG274J DG274K FD3A-4 FD3B-4 FD3C-4 FD3DS-4 FD3D-4 FD3ES-4 FD3EM-4 FD3E-4 FD3F-4 FD3G-4 FD
Order online

Generator Rating Table (4-pole 3-phase rating)
Model	Three Phase 50Hz 1500RPM
Power Factor	0.8		0.8		0.8		0.8		0.8		0.8		0.8		0.8
Volts
Star(W12&W13)	380		400		415				416		440		460		480
Delta(W12&W13)	220		230		240				240		254		266		277
Series Star(W11&W14)	380		400		415		380-416		416		440		460		480
Parallel Star(W11&W14)	190		200		208		190-208		208		220		230		240
Series Delta	220		230		240		220-240		240		254		266		277
Parallel delta	110		115		120		110-120		120		127		133		138.5
Winding No.	11		11		11		14		11		11		11		11
Rating	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW
TR274C	100	80	100	80	100	80	120	96	113	90	118	94	118	94	125	100
TR274D	125	100	125	100	125	100	140	112	140	112	150	120	150	120	150	120
TR274E	140	112	140	112	140	112	160	128	160	128	168	134	168	134	178	142
TR274EL	150	120	150	120	150	120	170	136	170	136	180	144	180	144	190	152
TR274F	160	128	160	128	160	128	180	144	181	144.8	190	152	190	152	200	160
TR274G	180	144	180	144	180	144	200	160	200	160	213	170.4	213	170.4	220	176
TR274H	200	160	200	160	200	160	237.5	190	237	189.6	245	196	245	196	250	200
TR274J	225	180	225	180	225	180	280	225	269	215.2	281	225	281	224.8	300	240
TR274K	250	200	250	200	250	200	300	240	291	232.8	300	240	300	240	313	250

Generator Rating Table (4-pole 1-phase rating)
Model	Single Phase 50Hz 1500RPM												Single Phase 60Hz 1800RPM
Power Factor	0.8		0.8		0.8		1.0		1.0		1.0		0.8		0.8		0.8		1		1		1
Volts
Series	220		230		240		220		230		240		220		230		240		220		230		240
Parallel	110		115		120		110		115		120		110		115		120		110		115		120
Winding No.	05		05		05		05		05		05		06		06		06		06		06		06
Rating	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW
TR274C	66	53	66	53	66	53	66	66	66	66	66	66	84	67	84	67	84	67	90	90	90	90	90	90
TR274D	74	59	74	59	74	59	74	74	74	74	74	74	96	77	96	77	96	77	100	100	100	100	100	100
TR274E	94	75	94	75	94	75	94	94	94	94	94	94	112	90	112	90	112	90	115	115	115	115	115	115
TR274EL	100	80	100	80	100	80	100	100	100	100	100	100	120	96	120	96	120	96	120	120	120	120	120	120
TR274F	110	88	110	88	110	88	110	110	110	110	110	110	135	108	135	108	135	108	135	135	135	135	135	135
TR274G	120	96	120	96	120	96	120	120	120	120	120	120	150	120	150	120	150	120	150	150	150	150	150	150
TR274H	140	112	140	112	140	112	140	140	140	140	140	140	156	125	156	125	156	125	156	156	156	156	156	156
