AC STAMFORD TYPE BRUSHLESS ALTERNATOR TR224 SINGLE PHASE THREE PHASE 50HZ 60HZ

Product Item : TR224
Category： ALTERNATOR
Stamford Type Alternator
4 poles 1500RPM 1800RPM
SIngle Phase Three Phase
Product description：DINGOL WERNA FARADAY FARRAND ALTERNATOR DG224C DG224D DG224E DG224F DG224G WR224C WR224D WR224E WR224F WR224G FD2A-4 FD2B-4 FD2C-4 FD2CL-4 FD2DS-4 FD2D-4
Order online

Generator Rating Table (4-pole 3-phase rating)
Model	Three Phase 50Hz 1500RPM
Power Factor	0.8		0.8		0.8		0.8		0.8		0.8		0.8		0.8		0.8
Volts
Star(W12&W13)	380		400		415		440				416		440		460		480
Delta(W12&W13)	220		230		240		254				240		254		266		277
Series Star(W11&W14)	380		400		415		440		380-416		416		440		460		480
Parallel Star(W11&W14)	190		200		208		220		190-208		208		220		230		240
Series Delta	220		230		240		254		220-240		240		254		266		277
Parallel delta	110		115		120		127		110-120		120		127		133		138.5
Winding No.	11		11		11		11		14		11		11		11		11
Rating	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW
TR224C	42.5	34	42.5	34	42.5	34	30	24	55	44	50	40	52.5	42	52.5	42	55	44
TR224D	50	40	50	40	50	40	37.5	30	62.5	50	60	48	62.5	50	62.5	50	65	52
TR224E	60	48	60	48	60	48	45	36	70	56	67.5	54	70	56	70	56	75	60
TR224F	72.5	58	72.5	58	72.5	58	55	44	85	68	83.8	67	87.5	70	87.5	70	93.8	75.04
TR224G	85	68	85	68	85	68	75	60	100	80	93.8	75	97.5	78	100	80	103.8	83.04

Model	Single Phase 50Hz 1500RPM												Single Phase 60Hz 1800RPM
Power Factor	0.8		0.8		0.8		1.0		1.0		1.0		0.8		0.8		0.8		1		1		1
Volts
Series	220		230		240		220		230		240		220		230		240		220		230		240
Parallel	110		115		120		110		115		120		110		115		120		110		115		120
Winding No.	05		05		05		05		05		05		06		06		06		06		06		06
Rating	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW
TR224C	28.0	22.4	28.0	22.4	28.0	22.4	28.0	28.0	28.0	28.0	28.0	28.0	37.5	30.0	37.5	30.0	37.5	30.0	37.5	37.5	37.5	37.5	37.5	37.5
TR224D	35.0	28.0	35.0	28.0	35.0	28.0	35.0	35.0	35.0	35.0	35.0	35.0	44.0	35.0	44.0	35.0	44.0	35.0	44.0	44.0	44.0	44.0	44.0	44.0
TR224E	40.0	32.0	40.0	32.0	40.0	32.0	40.0	40.0	40.0	40.0	40.0	40.0	50.0	40.0	50.0	40.0	50.0	40.0	50.0	50.0	50.0	50.0	50.0	50.0
TR224F	50.0	40.0	50.0	40.0	50.0	40.0	50.0	50.0	50.0	50.0	50.0	50.0	60.0	48.0	60.0	48.0	60.0	48.0	60.0	60.0	60.0	60.0	60.0	60.0
TR224G	60.0	48.0	60.0	48.0	60.0	48.0	60.0	60.0	60.0	60.0	60.0	60.0	70.0	56.0	70.0	56.0	70.0	56.0	75.0	75.0	75.0	75.0	75.0	75.0
