STAMFORD TYPE AC BRUSHLESS ALTERNATOR TR444 TR544

Product Item : TR444 TR544
Category： ALTERNATOR
Stamford Type Alternator
4 poles 1500RPM/1800RPM
Three Phase Single Phase
Product description：DINGOL WERNA FARADAY FARRAND ALTERNATOR WR444C WR444D WR444E WR444F WR544C WR544D WR544E WR544F DG444C DG444D DG444E DG444F DG544C DG544D DG544E DG544F FD4S-4 FD4MS-4 FD4M -4 FD4MP-4 FD4LS-4 FD4L-4 F
Order online

Generator Rating Table (4-pole 3-phase rating)
Model	Three Phase 50Hz 1500RPM								Three Phase 60Hz 1800RPM
Power Factor	0.8		0.8		0.8		0.8		0.8		0.8		0.8		0.8		0.8		0.8
Volts
Star(W12&W13)	380		400		415		440		380-416				416		440		460		480
Delta(W12&W13)	220		230		240		254		220-240				240		254		266		277
Series Star(W11&W14)	380		400		415		440		-		380-416		416		440		460		480
Parallel Star(W11&W14)	190		200		208		220		-		190-208		208		220		230		240
Series Delta	220		230		240		254		-		220-240		240		254		266		277
Parallel delta	110		115		120		127				110-120		120		127		133		138.5
Winding No.	11		11		11		11		13		14		11		11		11		11
Rating	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW
TR444C	250	200	250	200	250	200	250	200	300	240	300	240	287.5	230	300	240	300	240	313	250
TR444D	300	240	300	240	300	240	280	224	350	280	350	280	340	272	360	288	360	288	375	300
TRK444D	313	250	313	250	313	250	290	232	360	288	360	288	350	280	375	300	375	300	388	310
TR444E	325	260	325	260	325	260	325	260	-	-	-	-	381	305	400	320	400	320	415	332
TRK444E	350	280	350	280	350	280	350	280	-	-	-	-	400	320	420	338	420	336	430	344
TR444F	375	300	375	300	375	300	375	300	475	300	-	-	444	355	455	364	463	370	475	380
TRK444F	400	320	400	320	400	320	400	320	500	400	-	-	454	363	480	384	500	400	500	400

TR544C	450	360	450	360	450	360	450	360	500	400	500	400	525	420	550	440	581	465	594	475
TR544D	500	400	500	400	500	400	500	400	625	500	625	500	575	460	594	475	625	500	644	515
TR544ES	563	450	563	450	563	450	563	450	650	520	650	520	625	500	650	520	670	536	700	560
TR544E	600	480	600	480	600	480	600	480	688	550	688	550	681	545	713	570	732	586	750	600
TR544EL	625	500	625	500	625	500	625	500	710	568	710	568	700	560	735	588	755	604	765	612
TR544F	670	536	670	536	670	536	650	520	800	640	800	640	738	590	775	620	800	640	825	660
