AC STAMFORD TYPE BRUSHLESS ALTERNATOR TR634 TR734

Product Item : TR734C
Category： ALTERNATOR
Stamford Type Alternator
4 poles 1500RPM/1800RPM
Three Phase Single phase
Product description：DINGOL WERNA FARADAY FARRAND ALTERNATOR DG634B DG634C DG634D DG634E DG634F DG734B DG734C DG734D DG734E DG734E DG734F DG734G WR634B WR634C WR634D WR634E WR634F WR734B WR734C WR734D WR734E WR734E WR734F
Order online

Generator Rating Table (4-pole 3-phase rating)
Model	Three Phase 50Hz 1500RPM								Three Phase 60Hz 1800RPM
Power Factor	0.8		0.8		0.8		0.8		0.8		0.8		0.8		0.8		0.8		0.8
Volts
Star(W12&W13)	380		400		415		440		380-416				416		440		460		480
Delta(W12&W13)	220		230		240		254		220-240				240		254		266		277
Series Star(W11&W14)	380		400		415		440		-		380-416		416		440		460		480
Parallel Star(W11&W14)	190		200		208		220		-		190-208		208		220		230		240
Series Delta	220		230		240		254		-		220-240		240		254		266		277
Winding No.	11/12		11/12		11/12		11/12		13		14		11/12		11/12		11/12		11/12
Rating	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW
TR634B	710	568	750	600	750	600	680	544	938	750	938	750	810	648	855	684	895	716	938	750
TR634C¹	760	608	800	640	800	640	725	580	-	-	-	-	865	692	916	732.8	958	766.4	1000	800
TR634D	865	692	910	728	910	728	825	660	1063	850	1063	850	986	788.8	1034	827.2	1090	872	1138	910
TR634E	950	760	1000	800	1000	800	910	728	1250	1000	1250	1000	1083	866.4	1145	916	1197	957.6	1250	1000
TR634F	1090	872	1130	904	1130	904	1025	820	1320	1056	1320	1056	1204	963.2	1274	1019	1332	1066	1390	1112
TR634G	1190	952	1250	1000	1250	1000	1135	908	1500	1200	-	-	1310	1048	1386	1109	1449	1159	1513	1210

TR734B	1360	1088	1400	1120	1400	1120	1375	1100	1560	1248	-	-	1525	1220	1625	1300	1655	1324	1690	1352
TR734C	1505	1204	1550	1240	1550	1240	1520	1216	1770	1416	-	-	1705	1364	1815	1452	1855	1484	1890	1512
TR734D	1615	1292	1650	1320	1650	1320	1620	1296	1915	1532	-	-	1815	1452	1935	1548	1975	1580	2015	1612
TR734E	1845	1476	1900	1520	1900	1520	1865	1492	-	-	-	-	2070	1656	2210	1768	2250	1800	2300	1840
TR734F	2020	1616	2080	1664	2080	1664	2040	1632	2500	2000	-	-	2345	1876	2500	2000	2550	2040	2600	2080
TR734G	2135	1708	2200	1760	2200	1760	2160	1728	-	-	-	-	2420	1936	2535	2028	2625	2100	2750	2200
TR734H	2270	1816	2340	1872	2340	1872	2300	1840	-	-	-	-	2525	2020	2640	2112	2725	2180	2830	2264
