AC STAMFORD TYPE BRUSHLESS ALTERNATOR 164 SINGLE PHASE THREE PHASE
- Product Item : TR164
- Category： ALTERNATOR
- Stamford Type Alternator
- 1500RPM 1800RPM
- Three Phase Single Phase
- 50HZ 60HZ
- Product description：DINGOL WERNA FARADAY FARRAND ALTERNATOR DG164A DG164B DG164C DG164D WR164A WR164B WR164C WR164D FD1A-4 FD1B-4 FD1C-4 FD1D-4
|
Generator Rating Table (4-pole 3-phase rating) |
||||||||||||||||||
| Model | Three Phase 50Hz 1500RPM | |||||||||||||||||
| Power Factor | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | |||||||||
| Volts | ||||||||||||||||||
| Star(W12&W13) | 380 | 400 | 415 | 440 | 416 | 440 | 460 | 480 | ||||||||||
| Delta(W12&W13) | 220 | 230 | 240 | 254 | 240 | 254 | 266 | 277 | ||||||||||
| Series Star(W11&W14) | 380 | 400 | 415 | 440 | 380-416 | 416 | 440 | 460 | 480 | |||||||||
| Parallel Star(W11&W14) | 190 | 200 | 208 | 220 | 190-208 | 208 | 220 | 230 | 240 | |||||||||
| Series Delta | 220 | 230 | 240 | 254 | 220-240 | 240 | 254 | 266 | 277 | |||||||||
| Parallel delta | 110 | 115 | 120 | 127 | 110-120 | 120 | 127 | 133 | 138.5 | |||||||||
| Winding No. | 11 | 11 | 11 | 11 | 14 | 11 | 11 | 11 | 11 | |||||||||
| Rating | KVA | KW | KVA | KW | KVA | KW | KVA | KW | KVA | KW | KVA | KW | KVA | KW | KVA | KW | KVA | KW |
| TR164A | 8.1 | 6.5 | 8.1 | 6.5 | 8.1 | 6.5 | 6.2 | 5.0 | 9.6 | 7.7 | 9.6 | 7.7 | 10.2 | 8.2 | 10.2 | 8.2 | 10.2 | 8.2 |
| TR164B | 11 | 8.8 | 11 | 8.8 | 11 | 8.8 | 8.4 | 6.7 | 13 | 10.4 | 13 | 10.4 | 13.8 | 11 | 13.8 | 11 | 13.8 | 11 |
| TR164C | 13.5 | 10.8 | 13.5 | 10.8 | 13.5 | 10.8 | 11 | 8.8 | 16 | 12.8 | 16 | 12.8 | 16.9 | 13.5 | 16.9 | 13.5 | 16.9 | 13.5 |
| TR164D | 16 | 12.8 | 16 | 12.8 | 16 | 12.8 | 13.5 | 10.8 | 20 | 16 | 18.9 | 15.1 | 20 | 16 | 20 | 16 | 20 | 16 |
| Generator Rating Table (4-pole 1-phase rating) | ||||||||||||||||||||||||
| Model | Single Phase 50Hz 1500RPM | Single Phase 60Hz 1800RPM | ||||||||||||||||||||||
| Power Factor | 0.8 | 0.8 | 0.8 | 1.0 | 1.0 | 1.0 | 0.8 | 0.8 | 0.8 | 1 | 1 | 1 | ||||||||||||
| Volts | ||||||||||||||||||||||||
| Series | 220 | 230 | 240 | 220 | 230 | 240 | 220 | 230 | 240 | 220 | 230 | 240 | ||||||||||||
| Parallel | 110 | 115 | 120 | 110 | 115 | 120 | 110 | 115 | 120 | 110 | 115 | 120 | ||||||||||||
| Winding No. | 05 | 05 | 05 | 05 | 05 | 05 | 06 | 06 | 06 | 06 | 06 | 06 | ||||||||||||
| Rating | KVA | KW | KVA | KW | KVA | KW | KVA | KW | KVA | KW | KVA | KW | KVA | KW | KVA | KW | KVA | KW | KVA | KW | KVA | KW | KVA | KW |
| TR164A | 5.4 | 4.3 | 5.4 | 4.3 | 5.4 | 4.3 | 6.8 | 6.8 | 6.8 | 6.8 | 6.8 | 6.8 | 6.4 | 5.1 | 6.4 | 5.1 | 6.4 | 5.1 | 8.2 | 8.2 | 8.2 | 8.2 | 8.2 | 8.2 |
| TR164B | 7.4 | 5.9 | 7.4 | 5.9 | 7.4 | 5.9 | 8.4 | 8.4 | 8.4 | 8.4 | 8.4 | 8.4 | 8.8 | 7.0 | 8.8 | 7.0 | 8.8 | 7.0 | 11.0 | 11.0 | 11.0 | 11.0 | 11.0 | 11.0 |
| TR164C | 9.0 | 7.2 | 9.0 | 7.2 | 9.0 | 7.2 | 11.0 | 11.0 | 11.0 | 11.0 | 11.0 | 11.0 | 10.8 | 8.6 | 10.8 | 8.6 | 10.8 | 8.6 | 13.5 | 13.5 | 13.5 | 13.5 | 13.5 | 13.5 |
| TR164D | 10.8 | 8.6 | 10.8 | 8.6 | 10.8 | 8.6 | 13.0 | 13.0 | 13.0 | 13.0 | 13.0 | 13.0 | 13.5 | 10.8 | 13.5 | 10.8 | 13.5 | 10.8 | 16.5 | 16.5 | 16.5 | 16.5 | 16.5 | 16.5 |
We doing generator set ,engine ,alternator and engine spare parts for below
brands:Cummins,Perkins,Doosan,SDEC,Deutz,Weichai,Faw ,Lovol,Ricardo, AKSA generator and so on .
If you have any thing need please feel free to contact with us.
